Product Details:
|
| Parts Name: | RC Drill Bit | Brand: | JCDRILL |
|---|---|---|---|
| Color: | Customized | Factory Visit: | Support |
| Sample Order: | Support | Usage: | Hole Drlling |
| High Light: | oil well rc drill bit,dth rc drill bit,90mm diameter rc drill bit |
||
Russia best selling oil well use rc drill bit/Reverse circulation bit
1.Based on previous experience of ordinary hammers, combined with the features of reverse circulation hammer, optimized internal structure and ideal energy transfer, thus ensuring the series of hammers drilling with fast, smooth and continuous sampling.
2.The internal structure is very simple with components of high rigidity, thus ensuring long life and easy maintenance of the hammer.
3. The collection tube adopts an integrative design and can be replaced without disassembling the hammer. With carburizing treatment, it has good abrasive resistance.
4. Equipped with bits designed with patent. Simply by replacing the drill bit, the same hammer can drill holes of different sizes ensuring that the sample is not contaminated.
5. In different conditions such as loose soil, hard rock and plenty of water exists, sampling can be done well.
Specification
| Specification | Head Shape | Head Diameter(mm) | Shank Length | Spline | Port Holes | Weight(Kg) | |
| RE004 | RE004-115 | Drop-Center Face | 115 | 271 | 8 | 2 | 11.5 |
| RE004-121 | Drop-Center Face | 121 | 271 | 8 | 2 | 12.1 | |
| RE004-124 | Drop-Center Face | 124 | 271 | 8 | 2 | 12.3 | |
| RE004-127 | Drop-Center Face | 127 | 271 | 8 | 2 | 12.5 | |
| RE542 | RE542-121 | Drop-Center Face | 121 | 225 | 8 | 2 | 10.7 |
| RE542-124 | Drop-Center Face | 124 | 225 | 8 | 2 | 11 | |
| RE542-127 | Drop-Center Face | 127 | 225 | 8 | 2 | 11.2 | |
| RE542-133 | Drop-Center Face | 133 | 225 | 8 | 2 | 11.4 | |
| PR52 | PR52-133 | Drop-Center Face | 133 | 282 | 8 | 2 | 16.5 |
| PR52-136 | Drop-Center Face | 136 | 282 | 8 | 2 | 16.7 | |
| PR52-140 | Drop-Center Face | 140 | 282 | 8 | 2 | 16.9 | |
| PR52-143 | Drop-Center Face | 143 | 282 | 8 | 2 | 17.1 | |
| PR54R | PR54R-136 | Drop-Center Face | 136 | 261 | 8 | 2 | 18.3 |
| PR54R-140 | Drop-Center Face | 140 | 261 | 8 | 2 | 18.5 | |
| PR54R-143 | Drop-Center Face | 143 | 261 | 8 | 2 | 18.7 | |
| PR54R-146 | Drop-Center Face | 146 | 261 | 8 | 2 | 18.9 | |
| PR54R-165 | Drop-Center Face | 165 | 261 | 8 | 2 | 21 | |
| PR54R-178 | Drop-Center Face | 178 | 261 | 8 | 2 | 22.5 | |
Features
1) Face design: flat, convex, concave
2) Inserts design: spherical, ballistic, parabolic
3) Designed to work with RC hammers
4) Bit diameter: 90mm to 213mm
5) Reliable quality
6) Long service life
7) Smooth flushing effect
Delivery
FAQ
Q: Are you original manufacturer?
A: Yes, we JCDRILL is a official leading manufacture in drilling machinery in China and we have the whole series products you need.
Q: Which payment terms are available to us?
A: T/T term or L/C term. On T/T term, 30% down payment is required in advance, and 70% balance shall be settled before shipment.On L/C term, a 100% irrevocable L/C without "soft clauses" can be accepted.
Q: How long will the delivery time take?
A: Normally mud pump products will take about 3-15 days to produce the ordered machines. Most of the time, we can have an immediate delivery of our regular machines in 15 days.
Q: How about after sales service?
A: 365×24 Year-round Service We are committed to year-round 24-hour service even during holidays, in line with our policy of always providing "a response within 15 minutes and job completion within 24 hours."
Q:Spare Parts When You Need Them
A:We have spare parts centers across continents that stock specialist spare parts. We promise that spare parts will be delivered within 72 hours or no more than one week.
