13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity

China 13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity supplier
13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity supplier 13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity supplier 13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity supplier 13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity supplier 13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity supplier

Large Image :  13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity

Product Details:

Place of Origin: Beijing,China
Brand Name: JCDRILLS
Certification: ISO,CE
Model Number: Z-30W

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotation
Packaging Details: Standard export package
Delivery Time: In stock or as order quantity
Payment Terms: T/T, L/C, D/P, Western Union, MoneyGram
Supply Ability: 2000pcs/Year
Contact Now
Detailed Product Description
Model Number: Z-30W Loading Capacity: 60cbm/h
Bucket Capacity: 0.3cbm Track Gauge: 600mm
Power: Electric Motor Unloading Height: 1300mm
Weight: 4300Kgs Motor Power: 13kw
Walking Power: 10.5 Loading Width: 2200-2500mm

13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity





Z-30W Electric Mucker Mining Machine

Application
Z series Rock Loaders are designed as light,compact,flexible,easy operated and stable working equipment for underground mining,suitable for normal rocks,stones,grits,iron mine,gold mine,granite mine,and other metal or nonmetal mines.Maximum size of the loadable rocks can be 500mm diameter.And they gain highest efficiency by loading 100-400mm diameter rocks.They are suitable for level tunnels(8 degree maximum)for various underground mines.They are designed as' electric or compressed air driven,single bucketed and automatic walking machines by loading at front and unloading at back.Of which,Z-20 series electric rock loaders won the First Product Title of Shandong Province and National Mechanical Industry in recent years.Z-30W Rock Loader is the national patent product.
Introduction

JCDRILL Z-30W tunnel electric rock loader is bucket style with front loading and back unloading, self-propelled. This type of tunnel mucking loader is suitable for nonferrous, gold mining various types of mine area or diversion tunnel project, with high durability, long life and other advantages. Z-30 tunnel mucking machine is not explosion-proof, don't use in the environment with methane and other flammable gases etc.00mm.



13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity

13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity
Specification

Model Z-20W Z-30W
load capacity 40cbm/h 60cbm/h
bucket capacity 0.2cbm 0.3cbm
loading Width 1900mm 2200-2500mm
Discharge height (H) 1250mm 1300mm
Dumping reach (S) 350mm 350mm
Max operating height (H2) 1940mm 2250mm
Travel speed 0.99m/s 0.99m/s
motor model JI2-8 JI2-8
motor power 2x10.5kw 2x13kw
track gauge   600mm (customized) 600mm (customized)
overall dimension L (bucket is down) 2120mm 2590mm
W 1070mm 1200mm
H (bucket is down) 1305mm 1443mm

machine weight   3400kg 4300kg

Packing& Delivery
13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity
Service
13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity

13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity
In our after sales service system, We establish perfect control system strictly according to ISO-9000 series, in this system, technology date and problem solve solution and preventive measures will be provided in any maintain project, all the spare parts will be used in new OEM products with installation instructions, packing list, manufacturer's instruction, qualification and Warranty certificate.
We provide "one equipment & one case, endless service, namely the after sales service begin from the order confirmation, last for the working life of the equipment.
Purchase Process
13kw Crawler Mucking Loader / Tunnel Mucking Equipment 60cbm / H Loading Capacity
FAQ
Q1. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q2. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q3. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q4. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and
the courier cost.
Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q6: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from
.
