3 Inch DTH Drilling Tools DTH Hammer Button Drill Bit For Small Hole Drilling

3 Inch DTH Drilling Tools DTH Hammer Button Drill Bit For Small Hole Drilling
3 Inch DTH Drilling Tools DTH Hammer Button Drill Bit For Small Hole Drilling 3 Inch DTH Drilling Tools DTH Hammer Button Drill Bit For Small Hole Drilling 3 Inch DTH Drilling Tools DTH Hammer Button Drill Bit For Small Hole Drilling

Large Image :  3 Inch DTH Drilling Tools DTH Hammer Button Drill Bit For Small Hole Drilling

Product Details:
Place of Origin: Hebei,China
Brand Name: JCDRILLS
Certification: ISO,CE
Model Number: CIR90-90mm
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: Negotation
Packaging Details: Standard export package
Delivery Time: In stock or as order quantity
Payment Terms: T/T, L/C, D/P, Western Union, MoneyGram
Supply Ability: 20000pcs/Year

3 Inch DTH Drilling Tools DTH Hammer Button Drill Bit For Small Hole Drilling

Description
Model Number: HD25-76mm Type: DTH Button Bits
Usage: Mining, Coal, Iron Ore, Gold Mining Drilling Material: Tungsten Carbide
Shank: IR CIR Button Bit Shape: Spherical And Ballistic
Face Shape: Flat Shape And Drop-center Shape Body Type: Normal Type And Retract Type
Angle: 76-90mm Flushing Hole: 2
High Light:

dth drill bits

,

down the hole hammer bits

  76mm middle pressure 3inch dth hammer button bits for small hole drilling by down the hole drilling method



Application

DTH Drill Button Bits are produced from premium quality nickel-alloy steel for increased durability and wear characteristics. Specific heat treatment standards and special “stress relief” processes ensure consistent performance.



DTH hammer bits are designed for maximum performance and hole cleaning ability and high penetration rate.

We can design and manufacture according to customer's requirement of the down the hole bits Diameter,No. air holes,carbide button shape and the face shape.

Characteristics

Product Name: rock drill tungsten carbide DTH button bits





Description:

rock drill tungsten carbide DTH button bits

DTH button bit are used for blast hole drilling.

Working with DTH hammer, mainly applied in Mining,

Marble quarry or well drilling and other construction projects.

Material: High quality carbide and High quality carbon steel
MOQ: No requirement for testing and trial order
Compatibility Series: COP/ SD/ DHD/ IR/ Mission/ QL/ BR/ CIR etc

Specification

Drill Bits Bit Dia.(mm) No.Air Holes Gauge Buttons Front Buttons

Weight

(kg)

Parts No.

COP32

3'' Middle Pressure DTH Drill Bit with Flat Concave Convex Drop Center Bit Face

85 2 6×13 4×12 4.2 COP32-85
90 2 6×14 4×12 4.5 COP32-90
95 2 6×14 4×13 4.7 COP32-95
100 2 6×14 5×12 5.0 COP32-100
105 2 6×14 5×13 5.3 COP32-105

BR3

3'' Middle Pressure DTH Drill Bit with Flat Concave Convex Drop Center Bit Face

85 2 6×13 4×12 3.8 BR3-85
90 2 6×14 4×12 4.0 BR3-90
95 2 6×14 5×12 4.3 BR3-95
100 2 8×13 6×13 4.8 BR3-100
105 2 8×13 6×13 5.2 BR3-105

3 Inch DTH Drilling Tools DTH Hammer Button Drill Bit For Small Hole Drilling 2

Packing& Delivery                                                                                                                                        ​

3 Inch DTH Drilling Tools DTH Hammer Button Drill Bit For Small Hole Drilling 3

Service

3 Inch DTH Drilling Tools DTH Hammer Button Drill Bit For Small Hole Drilling 4

In our after sales service system, We establish perfect control system strictly according to ISO-9000 series, in this system, technology date and problem solve solution and preventive measures will be provided in any maintain project, all the spare parts will be used in new OEM products with installation instructions, packing list, manufacturer's instruction, qualification and Warranty certificate.


We provide "one equipment & one case, endless service, namely the after sales service begin from the order confirmation, last for the working life of the equipment.

Purchase Process                                                                                                                                              ​

3 Inch DTH Drilling Tools DTH Hammer Button Drill Bit For Small Hole Drilling 5     3 Inch DTH Drilling Tools DTH Hammer Button Drill Bit For Small Hole Drilling 6
