Rock Drilling Atlas Copco Portable Screw Air Compressor Diesel Engine Powered

JCdrill---The best and Specilized "one-stop selection sourcing platform“ for drilling rig and tools. —— Orlan

—— Orlan

The trailer water drilling rig TWD200 is really good borehole machine,beasy operation,high efficiency and good price. —— Кочетков Юрий

—— Кочетков Юрий

The hydraulic rotary water well drilling rig JKS300,JKCS400 drilling by DTH hammer and mud pump,very good quality and considerate after sales service!

—— Mr. Mohammed Seif

We start use the JK580 DTH rock drilling rig since 2009,now we have 6set working in our customer's mining site,perfect machine with reasonable price.

—— Gocha Rostiashvili

I'm Online Chat Now

Rock Drilling Atlas Copco Portable Screw Air Compressor Diesel Engine Powered

China Rock Drilling Atlas Copco Portable Screw Air Compressor Diesel Engine Powered supplier
Rock Drilling Atlas Copco Portable Screw Air Compressor Diesel Engine Powered supplier Rock Drilling Atlas Copco Portable Screw Air Compressor Diesel Engine Powered supplier Rock Drilling Atlas Copco Portable Screw Air Compressor Diesel Engine Powered supplier

Large Image :  Rock Drilling Atlas Copco Portable Screw Air Compressor Diesel Engine Powered

Product Details:

Place of Origin: China
Brand Name: Atlas Copco
Certification: ISO,CE
Model Number: XAHS186Dd

Payment & Shipping Terms:

Minimum Order Quantity: 1Set
Price: Negotation
Packaging Details: standard export transportation package
Delivery Time: 2Weeks
Payment Terms: T/T, L/C, D/P, Western Union
Supply Ability: 2000Set/Year
Contact Now
Detailed Product Description
Model Number: XAHS186Dd Type: Portable/screw
Power Type: Diesel Engine/electric Application: Water Well Drilling/mining Drilling
Apacity Control: 0~100% Stepless Speed Regulation Flow: 10.5m3/min
Pressure: 7bar Color: Yellow

Rock Drilling Atlas Copco Screw Compressor , Portable Diesel Automatic Air Compressor



Application

One in three compressors sold throughout the World is manufactured by Atlas Copco. Produced in the World’s largest dedicated compressor manufacturing plant, our advanced research and development and proven products ensure we offer the best solution for all your compressed air needs.

High efficiency

The combination of a high efficient engine and the Atlas Copco compressor element guarantees high efficiency and reduced wear.

Low operational cost, high fuel autonomy

A stepless and fully automatic regulator varying the engine speed ensures a reduced power and fuel consumption.



We are agent of portable double screw air compressor of Atlas Copco,Sullair, Liutech,by which ,we can provide drilling rig users with high quality professional drill rig air compressor solution and relative after-sales service also.

Characteristics

High efficiency

The combination of a high efficient engine and the Atlas Copco compressor element guarantees high efficiency and reduced wear.

Low operational cost, high fuel autonomy

A stepless and fully automatic regulator varying the engine speed ensures a reduced power and fuel consumption.



We are agent of portable double screw air compressor of Atlas Copco,Sullair, Liutech,by which ,we can provide drilling rig users with high quality professional drill rig air compressor solution and relative after-sales service also.

Specification

Model Nominal volume flow Working Pressure Engine Outlet Valve Configuration
XAHS37 1.92m³/min 7 bar Deutz.D2011L02 2 x 3/4” G
XAHS107Dd 5.6m³/min 12bar Deutz.BF4M2011 3 x 3/4” G(1×1.5“optional)
XAS37 2m³/min 7bar Kubota D905 2 x 3/4” G
XAS47Kd 2.5m³/min 7bar Kubota D1105 2 x 3/4” G
XAS57 Dd 3m³/min 7bar Deutz.D2011L02 3x 3/4” G
XAS67 3.7m³/min 7bar Deutz.F3M2011 2x 3/4” G
XAS77 Dd 4.3m³/min 7bar Deutz.F3M2011 3x 3/4” G
XAS97 5.3m³/min 7bar Deutz.F3M2011 3x 3/4” G
XAS137Dd 7.5m³/min 7bar Deutz.BF4M2011 3x 3/4” G(1×1.5“optional)
XAHS186 10.5m³/min 12bar Deutz.TCD2013L04 3x 3/4” G, 1×1.5G
XAHS186Dd 11.1m³/min 7bar Deutz.BF4M2012C 3x 3/4” G, 1×1.5G
XATS156Dd 10m³/min 10.3bar Deutz.BF4M2012C 3x 3/4” G, 1×1.5G
XAVS136Dd 8m³/min 14bar Deutz.BF4M2012C 3x 3/4” G, 1×1.5G
XAVS196Dd 11.3m³/min 13.8bar Deutz. BF4M1013FC 3x 3/4” G, 1×1.5G
XAHS710CD 20.6m³/min 12bar Caterpillar C7 T3 1×2” G, 2x 3/4” G,
XAMS850CD 24m³/min 8.6bar Caterpillar C7 T3 1×2” G, 2x 3/4” G,
XATS800CD 21.9m³/min 10.3bar Caterpillar C7 T3 1×2” G, 2x 3/4” G,
XAVS650CD 18.6m³/min 14bar Caterpillar C7 T3 1×2” G, 2x 3/4” G,
XAXS600CD 16.6m³/min 17bar Caterpillar C7 T3 1×2” G, 2x 3/4” G,
XAHS950 26.6m³/min 12bar Caterpillar C9 T3 1×2.5” G
XAMS1150 31.2m³/min 8.6bar Caterpillar C9 T3 1×2.5” G
XATS1050 28.9m³/min 10.3bar Caterpillar C9 T3 1×2.5” G
XAVS900 24.4m³/min 14bar Caterpillar C9 T3 1×2.5” G
XRHS836 21.9m³/min 20bar Caterpillar C9 T3 1×2” G
XRS846 23.5m³/min 17bar Caterpillar C9 T3 1×2” G
XRVS716 19.7m³/min 25bar Caterpillar C9 T3 1×2” G
XRHS1096 30.5m³/min 20bar Caterpillar C13 T3 1×2” G
XRHS1096 27.7m³/min 25bar Caterpillar C13 T3 1×2” G

Rock Drilling Atlas Copco Portable Screw Air Compressor Diesel Engine PoweredPacking& Delivery

Rock Drilling Atlas Copco Portable Screw Air Compressor Diesel Engine Powered

Service

12'' High Pressure DTH hammer for fundation,construction and borehole drilling ,305-445mm hole range

In our after sales service system, We establish perfect control system strictly according to ISO-9000 series, in this system, technology date and problem solve solution and preventive measures will be provided in any maintain project, all the spare parts will be used in new OEM products with installation instructions, packing list, manufacturer's instruction, qualification and Warranty certificate.


We provide "one equipment & one case, endless service, namely the after sales service begin from the order confirmation, last for the working life of the equipment.
