JRC500 500m Depth 100rpm Deep Rock Drilling Rig

JRC500 500m Depth 100rpm Deep Rock Drilling Rig
JRC500 500m Depth 100rpm Deep Rock Drilling Rig JRC500 500m Depth 100rpm Deep Rock Drilling Rig JRC500 500m Depth 100rpm Deep Rock Drilling Rig JRC500 500m Depth 100rpm Deep Rock Drilling Rig JRC500 500m Depth 100rpm Deep Rock Drilling Rig JRC500 500m Depth 100rpm Deep Rock Drilling Rig JRC500 500m Depth 100rpm Deep Rock Drilling Rig

Large Image :  JRC500 500m Depth 100rpm Deep Rock Drilling Rig

Product Details:
Place of Origin: China
Brand Name: JCDRILL
Certification: ISO,CE
Model Number: JRC500
Payment & Shipping Terms:
Minimum Order Quantity: 1Set
Price: Negotation
Packaging Details: Standard export ocean transportation package
Delivery Time: In stock
Payment Terms: T/T, L/C, D/P, Western Union, MoneyGram
Supply Ability: 2000Set/year
Detailed Product Description
Model Number: JRC500 Application: RC Reverse Circulation Drilling
Drilling Depth: 500m Drilling Diameter: 105-350mm
Drill Rod: 3000mm Rock Hardness: F=8-16
Rotation Speed: 0-100rpm Working Pressure: 1.05-2.4Mpa
Air Consumption: 11.3-21 M³/min Feed Stroke: 3.66m
Rotary Torque: 8500-10000N.m Dust Collector: Wet & Dry Optional
Pull Back Capacity: 28Ton Name: Rc 500m Depth 100rpm Deep Rock Drilling Rig
High Light:

RC deep rock drilling rig

,

500m Depth rock drilling rig

,

100rpm deep rock drilling rig

JRC500 Deep Rock RC Drilling Rig for 500m Depth



Main Features

The machine adopts an integrated design of pumping station and drilling rig, and a walking crawler is set at the bottom of the fuselage, which effectively improves the efficiency of moving and steady drilling. It is especially suitable for drilling in narrow tunnels in coal mines.

Adopting the rotating pan structure (company patented technology), when the crawler chassis isnot moving, relying on the pan rotation, it can achieve +180° azimuth adjustment and -90°~+90" elevation and depression and adjustment to meet the omnidirectional mine tunnel Cloth hole demand.

JRC500 500m Depth 100rpm Deep Rock Drilling Rig 0

JRC500 500m Depth 100rpm Deep Rock Drilling Rig 1

Specifiction

1 Geology drilled   All kinds
2 Drilling Type   DTH & RC
3 Drill system and operation   Hydraulic
4 Hole Diameter mm Φ90—Φ400
5 Hole Depth m 500
6 Rotation Torque KN 85-100
7 Rotation Speed rpm 0-80 1st Gear
0-160 2nd Ger
8 Drill pipe diameter mm 76/89/114
9 Drill pipe length mm 4/4500
10 Max. Feed Speed M/min 18
11 Max. Lifting Speed M/min 5-20
12 Feed Stroke mm 3400
13 Max. Lifting force T 28
14 Lifting force of Main winch(Optional) T 4
15 Lifting force of hoist T 1.5
16 Lifting height of tool winch m 100
17 Diesel Engine type CUMMINS
18 Rated Horse power Kw 180
19 Electrical System Volt 24
20 Compressor Type Rotary Screw/Movable
21 Pressure Required Mpa 1.05—4.5
22 Air consumption m³/min 16—60
23 Net Weight T 13
24 Shipping Length mm 7550
25 Shipping Width mm 2260
26 Shipping Height mm 2700
27 Ground Clearance mm 300
28 Volume of Flow mm 20

JRC500 500m Depth 100rpm Deep Rock Drilling Rig 2

Service

Hydraulic DTH crawler type reverse circulation RC drilling rigAfter sales service system, We establish excellent control system strictly according to ISO-9000 series, in this system, technology date and problem solve solution and preventive measures will be provided in any maintain project, all the spare parts will be used in new OEM products with installation instructions, packing list, manufacturer's instruction, qualification and Warranty certificate.

We provide "one equipment & one case, endless service, namely the after sales service begin from the order confirmation, last for the working life of the equipment.

Warranty

Spare parts

Every machine issued shall enjoy a one-year/2000 working hour warranty period, during which we will repair or replace the defective parts free of charge if material or process defects occur and spare parts are in normal working condition.

JCDRILL is dedicated to provide our clients with genuine spare parts with the highest quality,exact fitness and appropriate function.with our global distributor network,you are guaranteed with fast deliveries and services



Certification

Hydraulic DTH crawler type reverse circulation RC drilling rig FAQ

Q: Are you original manufacturer? Q: Which payment terms are available to us? Q: Which Incoterms 2010 terms can we work?

A: Yes, we JCDRILL is a official leading manufacture in drilling machinery in China and we have the whole series products you need.





A: T/T term or L/C term. On T/T term, 30% down payment is required in advance, and 70% balance shall be settled before shipment. On L/C term, a 100% irrevocable L/C without "soft clauses" can be accepted.

A: We JCDRILL are a professional and international company, accept all Incoterms 2010 terms, normally we work on FOB, CIF, CFR, CIP.





Q: How long will the delivery time take? Q: How about after sales service?

Q:Spare Parts When You Need Them



A: Normally mud pump products will take about 3-15 days to produce the ordered machines. Most of the time, we can have an immediate delivery of our regular machines in 15 days.





A: 365×24 Year-round Service
We are committed to year-round 24-hour service even during holidays, in line with our policy of always providing "a response within 15 minutes and job completion within 24 hours."

A:We have spare parts centers across continents that stock specialist spare parts. We promise that spare parts will be delivered within 72 hours or no more than one week.
