Front Mounted Adjustable Hydraulic Crawler Drilling Rig For Water Conservatory Project

China Front Mounted Adjustable Hydraulic Crawler Drilling Rig For Water Conservatory Project supplier
Front Mounted Adjustable Hydraulic Crawler Drilling Rig For Water Conservatory Project supplier Front Mounted Adjustable Hydraulic Crawler Drilling Rig For Water Conservatory Project supplier

Large Image :  Front Mounted Adjustable Hydraulic Crawler Drilling Rig For Water Conservatory Project

Product Details:

Place of Origin: China (Mainland)
Brand Name: JCDRILL
Certification: ISO9001,CE
Model Number: AK50

Payment & Shipping Terms:

Minimum Order Quantity: 1set
Price: Negotation
Packaging Details: Nude
Delivery Time: 15 days.Negotiable
Payment Terms: T/T, Western Union, D/A, D/P, MoneyGramm,L/C
Supply Ability: 3000sets/year
Contact Now
Detailed Product Description
Brand: JCDRILL Condition: New
Weight: 120kg Warranty: 1year
Hole Depth: 50m Hole Diameter: 90-150mm

Front Mounted Adjustable hydraulic crawler drilling rig



Description

Our AK50 construction Anchor Drilling rig is used for drilling anchor holes in deep base pit of high building, anchor and reinforce side-slope for water conservatory project, water power station project, railways and highways. Especially used for drilling anchor holes in high position side-slope protection and drainage holes.

Application

Front Mounted Adjustable Hydraulic Crawler Drilling Rig For Water Conservatory Project

Charactaristic

1. It has great drilling capability, wide range of application , rapid drilling speed and high drilling efficiency, as well as powerful ability of eliminating accident.
2. Extension mechanism in the output spindle of top drive power head can protect drilling tools effectively. It can increase the hole inclination angle range and drill elevation angle holes, while setting the top drive power head and hole top plate toward the opposite direction.
3. A set of front-mounted adjustable columns on drill frame is used for adjusting the height of mast front-end, which makes it convenient to align with hole site.
4. Rig structure is separate group design, it offers good disassembility , rapid and convenient mount and transport, better working environment and lower labor strength as well as remote control and operation.
5. Mast can be fixed on staging immediately without drill frame with auxiliary parts (horizontal axle and buckles), which makes it possible for greatly reducing rig weight and fast moving.
6. The hydraulic motor, pump are world famous brand products, other main assembly are preferentially selected home made reputed products with high quality. All these ensure the rig has stable running performance, reliable product quality and long service life. It has good interchangeability due to the high grade of standardization and seriesization of wearing parts.
7. Fully hydraulic drive and operation, stepless shift, simple operation, convenient maintanance and few wearing parts.
8. The rig is suitable for various drilling methods such as carbide bit drilling, auger drilling, DTH hammer drilling, follow-up casing drilling, etc.

Specification

Drilling depth 50m
Drilling diameter ¢90 ~ 150 mm
Drill specifications ¢ 73 × 1500 mm ¢ 89 × 1500 mm
Drilling tilt angle 0 ~ 120 °
power head output speed (positive and negative) 5 ~ 120 rpm
Rated output torque of the power head 2000 Nm
Power head stroke 1800 mm
Mast slip stroke 500 mm
power head maximum pull force 30 kN
Power Head biggest feeding force 15 kN
Hydraulic system rated pressure 20 Mpa
Motor Type Y180M-4 Power 18.5 kW
Host layman size 3000 × 1000 × 1500 mm
Rig weight 1000 kg
Maximum part weight (excluding motor)

200 kg



If you need more details,please feel free let me know by email:sales3@rockdrillingrig.com.

Certification

Front Mounted Adjustable Hydraulic Crawler Drilling Rig For Water Conservatory Project

Delivery

Front Mounted Adjustable Hydraulic Crawler Drilling Rig For Water Conservatory Project

FAQ

Q: Are you original manufacturer? Q: Which payment terms are available to us? Q: Which Incoterms 2010 terms can we work?

A: Yes, we JCDRILL is a official leading manufacture in drilling machinery in China and we have the whole series products you need.





A: T/T term or L/C term. On T/T term, 30% down payment is required in advance, and 70% balance shall be settled before shipment. On L/C term, a 100% irrevocable L/C without "soft clauses" can be accepted.

A: We JCDRILL are a professional and international company, accept all Incoterms 2010 terms, normally we work on FOB, CIF, CFR, CIP.





Q: How long will the delivery time take? Q: How about after sales service?

Q:Spare Parts When You Need Them



A: Normally mud pump products will take about 3-15 days to produce the ordered machines. Most of the time, we can have an immediate delivery of our regular machines in 15 days.





A: 365×24 Year-round Service
We are committed to year-round 24-hour service even during holidays, in line with our policy of always providing "a response within 15 minutes and job completion within 24 hours."

A:We have spare parts centers across continents that stock specialist spare parts. We promise that spare parts will be delivered within 72 hours or no more than one week.



Service

JCDRILL provide users high quality Mining & Drilling solutions,we always focus on the strategic conception of "Survival by quality, Development by credit''.

We have specilized in research, development and produce of rock blasting drilling rig, water well drilling rig, diamond core drilling rig, anchor drilling rig,Mud pump and relative accessories & drilling services. constantly provide professional drilling solutions for all customers with our advanced technology, excellent equipment, strict testing means and excellent service network, which establish our brand "JINCHENG" a good image of market, now,we products account for 50% of domestic market and have been export to more than 40 countries, and we awarded ISO9001: 2000 in November, 2002.
With excellent technology and solid market service capabilities, we have both a sound marketing system and excellent service support system, which help us win confidence of customers both at home and abroad,we can provide drilling rig users with high quality professional air compressor solution and relative after-sales service also.
